SCPI Conformance Information
F-6
:SOURce
:TTL1
[:LEVel] <b>
[:LEVel]?
:TTL2
[:LEVel] <b>
[:LEVel]?
:TTL3
[:LEVel] <b>
[:LEVel]?
:TTL4
[:LEVel] <b>
[:LEVel]?
Command path to program digital output port bits:
Path to program Bit 1 of output port:
Set (1 or ON) or reset (0 or off).
Request status of Bit 1.
Path to program Bit 2 of output port:
Set (1 or ON) or reset (0 or off).
Request status of Bit 2.
Path to program Bit 3 of output port:
Set (1 or ON) or reset (0 or off).
Request status of Bit 3.
Path to program Bit 4 of output port:
Set (1 or ON) or reset (0 or off).
Request status of Bit 4.
:SYSTem
:POSetup RST|PRESet|SAV0|SAV1|
SAV2|SAV3|SAV4|SAV5|SAV6|
SAV7|SAV8|SAV9
:POSetup?
Select Power-on setup.
Request Power-on setup.
Trigger commands:
:ARM[:SEQuence[1]]
[:LAYer[1]]
:SOURce TLINk
:TCONÞgure
:DIRection SOURce |ACCeptor
:DIRection?
:ASYNchronous
:ILINe <n>
:ILINe?
:OLINe <n>
:OLINe?
LAYer2
:SOURce TLINk
:TCONÞgure
:DIRection SOURce|ACCeptor
:DIRection?
:ASYNchronous
:ILINe <n>
:ILINe?
:OLINe <n>
:OLINe?
Subsystem command path to conÞgure scan:
Path to program arm layer of scan:
Select Arm Layer 1 control source.
Path to conÞgure Triggers.
Enable (SOUR) or disable (ACC) Bypass.
Request the programmed direction.
Path to conÞgure asynchronous Trigger Link mode:
Select input line (1 to 6).
Request programmed input line.
Select output line (1 to 6).
Request programmed output line.
Path to program scan layer of scan.
Select Arm Layer 2 control source.
Path to conÞgure Trigger Link:
Enable (SOUR) or disable (ACC) Bypass.
Request the programmed direction.
Path to conÞgure asynchronous mode:
Select input line (1 to 6).
Request programmed input line.
Select output line (1 to 6).
Request programmed output line.
Table F-2 (continued)
Syntax of non-SCPI commands implemented by Model 7001
Command Description
