Keithley 7001

SCPI Conformance Information
F-7
Trigger commands:
:TRIGger[:SEQuence[1]]
:SOURceTLINk
:TCONÞgure
:PROTocol ASYNchronous|
SSYNchronous
:PROTocol?
:DIRection SOURce|ACCeptor
:DIRection?
:ASYNchronous
:ILINe <n>
:ILINe?
:OLINe <n>
:OLINe?
:SSYNchronous
:LINe <n>
:LINe?
Path to program channel layer of scan.
Select Trigger Layer Control Source.
Path to conÞgure Triggers:
Select protocol (asynchronous or semi-synchronous
Trigger Link.)
Request programmed protocol.
Enable (SOUR) or disable (ACC) Bypass.
Request the programmed direction.
Path to conÞgure asynchronous Trigger Link mode:
Select input line (1 to 6).
Request programmed input line.
Select output line (1 to 6).
Request programmed output line.
Path to conÞgure semi-synchronous Trigger Link mode:
Select trigger line (1 to 6).
Request programmed trigger line.
Table F-2 (continued)
Syntax of non-SCPI commands implemented by Model 7001
Command Description
