X5 FastMig
Operating manual - EN
For replacing the wire feed rolls, refer to "Installing and replacing feed rolls" on page47.
For replacing the wire guide tubes, refer to "Installing and replacing wire guide tubes" on page51
1.4 X5 Manual control panel (X5 FP 300R)
This section describes the controls and features of the X5 Wire Feeder 300 Manual control panel (membrane panel).
1. Left control knob
2. Right control knob
3. Trigger logic selection (2T/4T)
4. Process selection (MIG/MMA/Gouging)
5. Home button (default welding mode)
6. Weld data button
7. Settings button
For using the control panel, refer to "Using X5 Manual control panel" on page63.
© Kemppi
14 1920960 / 2039
