X5 FastMig
Operating manual - EN
Control knob functions in Home view
Left control knob:
In MIG mode: Wire feed speed adjustment
In 1-MIG mode: Wire feed speed adjustment
In MMA mode: Welding current adjustment
In Gouging mode: Current adjustment.
Right control knob:
In MIG mode: Welding voltage adjustment
In 1-MIG mode:Fine tuning of welding voltage (the welding voltage is defined by the active welding program)
In 1-MIG mode with Wise feature: Wise parameter adjustment (the welding voltage is defined by the active weld-
ing program)
In MMA mode:Dynamics adjustment.
3.3.2 Auto control panel: Memory channels
The memory channel view can be accessed either via the panel's view selection or by pressing the physical memory
channel shortcut button above the display (refer to "Using X5 Auto control panel" on page68 for more information).
The amount of available memory channels differs between different operation modes: MIG (100 channels), TIG (10
channels), MMA (10 channels) and gouging (10 channels).
The operation mode set in the panel Settings determines for which main welding process the memory channels are
shown.
Changing memory channel
Turn the right control knob to highlight the desired memory channel. The highlighted memory channel is auto-
matically activated.
Managing memory channels
The memory channels are managed through the Actions menu.
© Kemppi
70 1920960 / 2039
