X5 FastMig
Operating manual - EN
The pressure rolls' mounting pins have central axles attached to them, whereas the drive rolls' central axles act as drive
shafts attached directly to the wire feed mechanism/motor.
5. Remove the pressure rolls.
6. Pull the drive roll mounting caps off and remove the drive rolls.
7. Select the feed rolls according to the tables below.
Wire feed rolls, plastic
Filler wire mater-
ial
Feed roll profile
Filler wire dia-
meter (mm)
Feed roll iden-
tification
Drive roll code Pressure roll code
© Kemppi
48 1920960 / 2039
