X5 FastMig
Operating manual - EN
6. Replace the outlet guide tube (c) by pushing the old outlet tube out from either direction.
Wire guide tubes
Filler wire mater-
ial
Filler wire dia-
meter (mm)
Feed roll iden-
tification
Inlet tube Middle tube Outlet tube
Al, Ss (Fe, Mc, Fc)
0.6 SP007293 SP007273 SP016608
0.8−0.9 SP007294 SP007274 SP011440
1.0 SP007295 SP007275 SP011441
1.2 SP007296 SP007276 SP011442
1.4 SP007297 SP007277 SP016609
1.6 SP007298 SP007278 SP016610
2.0 SP007299 SP007279 SP016611
2.4 SP007300 SP007280 SP016612
Fe, Mc, Fc
0.6 (SP007293) (SP007273) SP016613
0.8−0.9 SP007536 (SP007274) SP016614
1.0 SP007537 (SP007275) SP016615
1.2 SP007538 (SP007276) SP016616
1.4 (SP007297) (SP007277) SP016617
1.4−1.6 SP007539 (SP007278) SP016618
2.0 SP007540 (SP007279) SP016619
2.4 SP007541 (SP007280) SP016620
(The materials mentioned inside brackets refer to secondary suitability.)
© Kemppi
52 1920960 / 2039
