2 Front-Panel Operation
48 Keysight 34420A Service Guide
C: MATH MENU
D: TRIGger MENU
1: STATS ) 2: NULL VALUE ) 3: SCALE GAIN ) 4 : SCALE OFST
1:STATS Recalls the values of minimum, maximum, standard
deviation, average, peak-to-peak, and number of readings.
2: NULL VALUE Selects independent null settings for voltage on channels 1
and 2, resistance, and temperature functions.
3: SCALE GAIN Sets the gain for linear scaling of the data.
4: SCALE OFST Sets the offset for linear scaling of data.
1: READ HOLD ) 2: TRIG DELAY ) 3: N SAMPLES
1: READ HOLD Selects the reading hold sensitivity band.
2: TRIG DELAY Specifies a time delay between the trigger and the start of
the measurement.
3: N SAMPLES Sets the number of samples taken per trigger.
