Front-Panel Operation 2
Keysight 34420A Service Guide 49
E: SYStem MENU
F: Input / Output MENU
1: RDGS STORE ) 2: SAVED RDGS ) 3: ERROR ) 4: TEST ) 5: CHART OUT ) 6: CHART SPAN )
7: CHART NULL ) 8: DISPLAY ) 9: COMMA ) 10: PRESET ) 11: REVISION
1: RDGS STORE Enables or disables reading memory.
2: SAVED RDGS Recalls readings stored in memory (up to 1024 readings).
3: ERROR Retrieves errors from the error queue (up to 20 errors).
4: TEST Performs a complete self-test or individual self-tests.
5: CHART OUT Enables or disables the chart recorder output (Analog Out).
6: CHART SPAN Sets the chart recorder output range (Analog Out).
7: CHART NULL S Sets the chart recorder output offset (Analog Out).
8: DISPLAY Enables or disables the front panel display.
9: COMMA Enables or disables a comma separator between digits in
the display.
10: PRESET Returns the meter to factory default settings.
11: REVISION Displays the meter’s firmware revision code.
1: GPIB ADDR ) 2: INTERFACE ) 3: BAUD RATE ) 4: PARITY ) 5: LANGUAGE
1: GPIBADDR Sets the GPIB bus address (0 to 30, default 22).
2: INTERFACE Selects either the GPIB or RS-232 remote interface.
3: BAUD RATE Sets the baud rate for RS-232 operation.
4: PARITY Selects even, odd, or no parity for RS-232 operation.
5: LANGUAGE Selects interface language, either SCPI or Keithley 181.
