12 Keysight 34970A/34972A Service Guide
The Front-Panel Menu at a Glance
Several of the front-panel keys guide you through menus to configure various
parameters of the instrument (see previous page). The following steps
demonstrate the menu structure using the key.
1 Press the menu key. You are automatically guided
to the first level of the menu. Rotate the knob to
view the other choices on the first level of the
menu.
The menu will automatically time out after about
20 seconds of inactivity. You will be returned to
the operation in progress prior to entering the
menu.
2 Press the same menu key again to move to the
next item of the menu. Typically, this is where you
choose parameter values for the selected
operation.
To Next Page
