Calibration Procedures 4
Keysight 34970A/34972A Service Guide 123
2 For each analog output, set each output value in the table below. Compare
measurement results to the appropriate test limits shown in the table.
Analog Output Adjustment
This adjustment procedure sets a zero adjustment and a gain adjustment
constant for each DAC output. You must perform all the adjustments on one
analog output channel before adjusting the other analog output channel.
1 Install the module in slot 100. Select the first analog output channel (104).
2 Connect an external DMM to the output terminals.
3 Set the analog output to 00.000 V.
4 Press
to enter the calibration menu. Press
again to begin the
adjustment procedure.
5 Use the knob, and to set the number in the display to the measured
output value and press
to complete the adjustment.
6 Set the analog output to 10.000 V.
7 Press
to enter the calibration menu. Press
again to begin the
adjustment procedure.
8 Use the knob, and to set the number in the display to the measured
output value and press to complete the adjustment.
9 Repeat steps 1 through 8 for Channel 105.
10 Perform the Voltage Output Verification Test on page 110 to verify the
adjustment.
DAC Output Quick Check Measured Output Error from Nominal 1 year
0.000 V
10.000 V Q
0.000 V
10.000 V
± 20 mV
± 45 mV
Install the 34907A module in the mainframe and allow a 45 minute warm-up
before performing these procedures.
