3 Front-Panel Overview
62 Keysight 34970A/34972A Service Guide
To Output a DC Voltage
The multifunction module (34907A) has two analog outputs capable of outputting
calibrated voltages between ±12 volts.
1 Select a DAC Output channel.
Select the slot containing the multifunction module and continue turning the
knob until DAC is displayed (channel 04 or 05).
2 Enter the output voltage ed itor.
3 Set the desired output voltage.
Use the knob and or keys to edit the individual digits.
4 Output the voltage from the selected DAC.
The output voltage will be displayed until you press another key or turn the
knob. To manually reset the output voltage to 0 volts, press .
+00.000 V DAC
+05.250VDAC
