4 Calibration Procedures
84 Keysight 34970A/34972A Service Guide
AC VOLTS Gain Verification Test
Configuration: AC Volts
LF 3 HZ:SLOW (in the Advanced menu)
1 Make sure you have read “Test Considerations” on page 76.
2 Select Channel 210, set the AC VOLTS function and the 3 Hz input filter. With
the slow filter selected, each measurement takes 7 seconds to complete.
Before executing each test, you must press to enable reading monitoring
on the selected channel (or use the ROUTe:MON command from the remote
interface).
3 Select each range in the order shown below. Compare measurement results to
the appropriate test limits shown in the table. (Be certain to allow for
appropriate source settling.)
Input
Range
Quick
Check
[a]
[a] Q: Quick performance verification test points.
Error from Nominal
V rms Frequency 24 hour 90 day 1 year
100 mV
100 mV
1 V
1 V
10 V
10 V
10 V
10 mV
[b]
100 V
100 V
300 V
300 V
[c]
[b] For this test, isolate the calibrator’s output from earth ground.
[c] Some calibrators may have difficulty driving the internal DMM and cable load at this V-Hz output. Use short, low
capacitance cable to reduce calibration loading. Verification can be performed at >195 Vrms. New test limits can
be computed from the accuracy specification shown in Chapter 1 for the actual test conditions used.
1 kHz
50 kHz
1 kHz
50 kHz
1 kHz
50 kHz
10 Hz
1 kHz
1 kHz
50 kHz
1 kHz
50 kHz
100 mV
1 V
10 V
100 mV
100 V
300V
Q
Q
Q
± 70 mV
± 150 mV
± 700 mV
± 1.5 mV
± 7 mV
± 15 mV
± 7 mV
± 34 mV
± 70 mV
± 150 mV
± 270 mV
± 600 mV
± 90 mV
± 160 mV
± 900 mV
± 1.6 mV
± 9 mV
± 16 mV
± 9 mV
± 45 mV
± 90 mV
± 160 mV
± 390 mV
± 690 mV
± 100 mV
± 170 mV
± 1 mV
± 1.7 mV
± 10 mV
± 17 mV
± 10 mV
± 46 mV
± 100 mV
± 170 mV
± 420 mV
± 720 mV
