Calibration Procedures 4

Keysight 34970A/34972A Service Guide 97

Connections for 34901A Verification Tests 1 through 5

Probe here

for L402

measurement.

Probe here for F501 measurement.

Probe here for F502 measurement.

Note: Be sure to probe the components at

the indicated locations on the module.
