Keysight E5260/E5270 Programming Guide, Edition 4 3- 9
Programming Examples
High-Speed Spot Measurements
High-Speed Spot Measurements
To perform high-speed spot measurements, use the following commands.
You can use the above commands regardless of the measurement mode (MM
command settings).
Function Command Parameters
Enables channels CN [chnum ... [,chnum] ... ]
Disables channels CL [chnum ... [,chnum] ... ]
Sets filter ON/OFF [FL] mode[,chnum ... [,chnum] ... ]
Sets series resistor ON/OFF [SSR] chnum[,mode]
Sets integration time
(Keysight E5270B can use
AAD/AIT instead of AV.)
[AV] number[,mode]
[AAD] chnum[,type]
[AIT] type,mode[,N]
Forces constant voltage DV, TDV chnum,vrange,output
[,comp[,polarity[,irange]]]
Forces constant current DI, TDI chnum,irange,output
[,comp[,polarity[,vrange]]]
Measures current TI, TTI chnum[,range]
Measures voltage TV, TTV chnum[,range]
Resets the time stamp TSR
Returns the time stamp at
this time
TSQ
