1- 30 Keysight E5260/E5270 Programming Guide, Edition 4
Programming Basics
Data Output Format
Binary Data Output Format
This section describes the binary data output format, and the elements of the data.
• “Data Format”
• “Data Elements”
NOTE
Data resolution
The resolution of binary data is as shown below.
• Measurement data: Measurement range / 50000
• Output data: Output range / 20000
Note that the resolution of the measurement data is larger than the resolution of the
high resolution A/D converter.
Data Format
The data output format depends on the measurement mode as shown below.
High Speed Spot Data <terminator>
Data is the value measured by the channel you specify by using the TI or TV
command.
Spot Data1 [Data2] . . . . <terminator>
DataN (N: integer) is the value measured by a channel. The order of Data is defined
by the MM command.
Pulsed Spot,
Quasi-Pulsed Spot
Data <terminator>
Data is the value measured by the channel you specify by using the MM command.
