Keysight E5260/E5270 Programming Guide, Edition 4 4- 59
Command Reference
Command Reference
FMT
The FMT command clears the E5260/E5270 output data buffer, and specifies the
data output format and the data terminator. For details about data output format, see
“Data Output Format” on page 1-22.
Query command output data is always stored in the query buffer in ASCII format,
regardless of this command.
If you do not enter this command, the data output format is same as the data format
by the FMT1,0 command.
NOTE Multi command statement is not allowed for this command.
Syntax FMT format[,mode]
Parameters format : Data output format. Integer expression. 1 to 5, 11, 12, 15, 21, 22, or 25.
See
Table 4-11.
mode : Source data output mode. Integer expression. 0 to 8. See Table 4-10.
You can select the source data returned with the measurement data. If
you do not specify this parameter, no source data is returned.
Example
Statements
OUTPUT @E5270;"FMT 1"
OUTPUT @E5270;"FMT 2,1"
Table 4-10 FMT mode parameter
mode Source data returned with measurement data
0 None (default setting). Only the measurement data is returned.
1 Data of the primary sweep source set by the WI/WV/PWI/PWV
command.
2 Data of the synchronous sweep source set by the WSI/WSV
command.
2 to 8 For the multi channel sweep measurement:
Data of the synchronous sweep source set by the WNX command.
The mode value must be the sweep source number (2 to 8) you want
to get data. For the sweep source number, refer to
“WNX” on page
4-136.
