Programming Examples
Multi Channel Sweep Measurements
Multi Channel Sweep Measurements
To perform multi channel sweep measurements, use the following commands.
Function Command Parameters
Enables channels CN [chnum ... [,chnum] ... ]
Disables channels CL [chnum ... [,chnum] ... ]
Sets filter ON/OFF [FL] mode[,chnum ... [,chnum] ... ]
Sets series resistor ON/OFF [SSR] chnum[,mode]
Sets integration time
(Keysight E5270B can use
AAD/AIT instead of AV.)
[AV] number[,mode]
[AAD] chnum[,type]
[AIT] type,mode[,N]
Sets sweep source timing
parameter
[WT] hold,delay
[,sdelay[,tdelay[,mdelay]]]
Sets auto abort function [WM] abort[,post]
Sets voltage sweep source WV chnum,mode,range,start,stop,step
[,comp[,Pcomp]]
Sets current sweep source WI
Sets synchronous sweep
source
a
a. The WNX command must be entered after the WV/WI command.
WNX N,chnum,mode,range,start,stop
[,comp[,Pcomp]]
Forces constant voltage DV, TDV chnum,range,output
[,comp[,polarity[,crange]]]
Forces constant current DI, TDI
Sets voltage measurement
range
[RV] chnum,range
Sets current measurement
range
[RI] chnum,range
[RM] chnum,mode[,rate]
Selects measurement mode MM 16,chnum[,chnum ... [,chnum] ... ]
Sets SMU operation mode [CMM] chnum,mode
Executes measurement XE
