Programming Basics
Getting Started
Table 1-1 Measurement Mode and Available Source Output Commands
The DV, DI, TDV, and TDI commands start to force the voltage or current
immediately when the command is executed. The other commands just set the
source channel condition, and the source channel starts the output by the start
trigger, such as the XE command. For more details of the commands, refer to
Chapter 4, “Command Reference.”
Example OUTPUT @E5270;"DV 1,0,5"
This example just forces 5 V using channel 1 (the module installed in slot 1 of the
E5260/E5270) with auto ranging.
Measurement Mode Command
Spot Measurement DV, DI, TDV, TDI
Staircase Sweep Measurement DV, DI, TDV, TDI, and WV(/WSV) or
WI(/WSI)
Pulsed Spot Measurement DV, DI, TDV, TDI, and PV/PT or PI/PT
Pulsed Sweep Measurement DV, DI, TDV, TDI, and
PWV/PT(/WSV) or PWI/PT(/WSI)
Staircase Sweep with Pulsed Bias
Measurement
DV, DI, TDV, TDI, and WV(/WSV) or
WI(/WSI), and PV/PT or PI/PT
Quasi-Pulsed Spot Measurement DV, DI, TDV, TDI, BDV
Linear Search Measurement DV, DI, TDV, TDI, and LSV(/LSSV) or
LSI(/LSSI)
Binary Search Measurement DV, DI, TDV, TDI, and BSV(/BSSV) or
BSI(/BSSI)
Multi Channel Sweep Measurement DV, DI, TDV, TDI, WNX, and WV or
WI
High Speed Spot Measurement DV, DI, TDV, TDI
