250 Keysight EXG and MXG X-Series Signal Generators User’s Guide

Basic Digital Operation for N5172B/82B with Options 653/655/656/657

Waveform Licensing

Locked MM/DD/YY The slot is locked and can no longer

be modified.

The waveform in this slot is licensed

to this signal generator for

unlimited playback.

Remaining Trial Time HH:MM The slot is in a trial period that is

available for 48 hours that begins

when a waveform is added.

During the trial period, the

waveform in this slot can be played,

cleared, or replaced with another

waveform.

Lock Required The trial period for the slot has

expired but the slot has not been

locked.

The slot can be cleared or replaced

with a different waveform but the

waveform cannot be played until

the slot is locked. A trial period is

no longer available.

Table 8-6 Waveform Licensing Slot Status Messages

Status Column Meaning Notes
