Keysight EXG and MXG X-Series Signal Generators User’s Guide 351

Using Avionics VOR/ILS Softkeys for N5171B/72B and N5181B/82B with Option 302

Using VOR [VHF Omnidirectional Range] Softkeys

To set or return the VOR subsystem parameters to a default state

1. Press Aux Fctn > Avionics > VOR

2. Press More 1 of 2

3. Press Recall Default Settings

Selecting this softkey returns the VOR system parameters to a set of default

state conditions.

VOR Menu Parameters Default State

VOR Mode OFF

Carrier Freq Index 1 108.00 MHz

Bearing menu Angle 0.00 Deg

Direction From

REF/VAR menu REF/VAR Freq 30.00 Hz

REF Deviation 480.0 Hz

VAR Depth 30.0%

SubCarrier Freq 9.96000 kHz

SubCarrier Depth 30.0%

COM/ID menu

a. For information on the COM/ID menu,

refer to

“Using COM/ID Softkeys” on page 354.

Default Chapter5
