372 Keysight EXG and MXG X-Series Signal Generators User’s Guide

Using Avionics VOR/ILS Softkeys for N5171B/72B and N5181B/82B with Option 302

Using ILS Localizer Softkeys

To set or return the ILS Localizer parameters to a default state

1. Press Aux Fctn > Avionics > ILS Localizer

2. Press More 1 of 2

3. Press Recall Default Settings

These softkeys return the ILS Localizer parameters

to a set of default state conditions.

ILS Localizer Menu Parameters Default State

ILS LOC Mode OFF

Carrier Freq Index 1 108.1 MHz

Left/Right menu Left Frequency 90 Hz

Right Frequency 150 Hz

Left/Right Phase 0.00 deg

DDM/SDM menu Fly Left/Right Left

DDM 0.0000

DDM uA 0.0 uA

DDM% 0.00%

SDM 40.0%

COM/ID menu

a. For information on the COM/ID menu,

refer to

“Using COM/ID Softkeys” on page 354.

Default Chapter5
