382 Keysight EXG and MXG X-Series Signal Generators User’s Guide
Using Avionics VOR/ILS Softkeys for N5171B/72B and N5181B/82B with Option 302
Using ILS Glide Slope Softkeys
To set the ILS Glide Slope up frequency
1. Press Aux Fctn > Avionics > ILS Glide Slope
2. Press Up/Down
3. Press Up Frequency
(Default <value> is 90 Hz.)
4. Select a <value> in Hz | kHz | MHz | GHz from 0 Hz to 6 MHz.
These softkeys set the ILS Glide Slope up frequency.
To set the ILS Glide Slope down frequency
1. Press Aux Fctn > Avionics > ILS Glide Slope
2. Press Up/Down
3. Press Down Frequency
(Default <value> is 150 Hz.)
4. Select a <value> in Hz | kHz | MHz | GHz from 0 Hz to 10 MHz.
These softkeys set the ILS Glide Slope down frequency.
16=109.55 16=332.45 36=111.55 36=332.75
17=109.70 17=333.20 37=111.70 37=333.50
18=109.75 18=333.05 38=111.75 38=333.35
19=109.90 19=333.80 39=111.90 39=331.10
20=109.95 20=333.65 40=111.95 40=330.95
