Keysight EXG and MXG X-Series Signal Generators User’s Guide 307
Using Custom Digital Modulation for N5172B/82B with Option 431 and 653/655/656/657
Differential Encoding
These symbol table offsets will result in one of the transitions, as shown.
Data Value 00000001
transition 1 state backward
with Symbol Table Offset –1
Data Value 00000010
transition 2 states forward
with Symbol Table Offset +2
Data Value 00000011
no transition
with Symbol Table Offset 0
Data Value 00000000
transition 1 state forward
with Symbol Table Offset +1
