18 Chapter 1
Introducing the N8241/2A AWGs
Front Panel Interface
11 Reset The “RST” button enables you to put the LAN configuration
of the instrument into a known state.
When you press this button the following settings are made
and the system reboots:
• IP Address is set to 192.168.EE.FF, where EE and FF are
the last two parts of the MAC address
(AA.BB.CC.DD.EE.FF). This is designed to prevent
multiple instruments from using the same default IP
address.
• Subnet Mask is set to 255.255.0.0
• DHCP is set to ON
• Auto IP is set to ON
• The instrument hostname is set to A-N82XXA-NNNNN,
where N82XXA is the instrument model number (such as
N8241A) and NNNNN represents the last five digits of
the instrument serial number.
12 TRIGGER IN/OUT These SMB trigger input and output connectors are used to
control the waveforms and create event-based signal
simulation. The connectors support LVTTL logic levels and
are functionally equivalent to Triggers/Markers 1-4, but have
additional latency.
13 10 MHz REF IN/OUT These SMB connectors can be used to input and output a
10 MHz reference.
Item Description
# Name
