6 53210A Math, Graphing, and Data Logging
172 Keysight 53210A User’s Guide
– When ‘Statistics’ (under the Math key) are enabled, the minimum and
maximum values from the reading statistics are used.
– If readings are in progress and ‘Statistics’ are off, the instrument will select a
minimum and a maximum value from (up to) the last 10,000 readings taken.
– If no previous readings are available, a minimum bin range of 0 and a
maximum bin range of 1 000 000 000.0 are set.
Automatic Range Setting
Alternately, lower and upper range values can be set automatically based on a
minimum value and maximum value obtained from the first ‘n’ number of readings
taken.
Automatic range selection is enabled with the commands:
CALCulate2:TRANsform:HISTogram:RANGe:AUTO {OFF|ON}
CALCulate2:TRANsform:HISTogram:RANGe:AUTO? (query form)
ON
- enables automatic selection of the histogram lower and upper range values.
OFF - disables automatic selection.
Following a reset (
*RST) or instrument preset (SYSTem:PRESet) automatic range
selection is enabled.
The number of readings from which the minimum and maximum range values are
selected (
ON) is set with the command:
