KidKraft WINDALE - Attach Seat Support

34
Step 18: Attach Seat Support
A: On the Swing Wall measure 27” up from the bottom of (2223) SW Ground on each (2215) Post. Place top of
(2217) Seat Support at marked location and attach to both posts with 4 (S2) #8 x 1-1/2” Wood Screws. (g. 18.1)
Wood Parts Hardware
4 x #8 x 1-1/2” Wood Screw
1 x Seat Support 1 x 4 x 35-7/8”
2217
S2
2215
S2
x 4
Fig. 18.1
Swing Wall
2217
2223
2215
27”
