Step 24: Attach Door Stop to Fort
A: From inside the fort measure 16-7/8” up from the bottom of (2213) Front Divider and attach (2209) Door Stop
ush to the inside edge of (2213) Front Divider with 3 (S15) #8 x 1-3/4” Wood Screws. (g. 24.1)
B: In the notched out opening of (2209) Door Stop attach the Magnetic Catch using 2 (S18) #6 x 1” Wood Screws.
(g. 24.2 and 24.3) Important: Use a hand held screw driver and DO NOT over tighten.
3 x #8 x 1-3/4” Wood Screw
2 x #6 x 1” Wood Screw
S15
1 x Door Stop 5/4 x 3 x 10”
2209
Fig. 24.1
Front Wall
Flush
2209
2213
16-7/8``
S15
Fig. 24.2
Fig. 24.3
2209
S18
Magnetic Catch
Other Parts
1 x Magnetic Catch
S18
