KidKraft WINDALE - Attach Slide to Fort

49
Hardware
Other Parts
A: Place Slide in the centre between (2213) Front Divider and (2215) Post. (g. 29.1 and 29.2)
B: Pre-drill with a 1/8” drill bit then attach slide to fort through oor boards and into (2218) Short Joist using 3
(S7) #12 x 2” Pan Screws. (g. 29.2)
Step 29: Attach Slide to Fort
Fig. 29.1
2215
Fig. 29.2
2213
3 x #12 x 2” Pan Screw
S7
1 x Slide
Slide
2215
S7
Slide
(hidden behind boards)
1906
2218
(hidden behind 1906)
