KidKraft WINDALE - Ground Stakes and Final Securing

40
A: Drive 2 (0318) Ground Stakes 10-1/2” into the ground at both ends of (2223) SW Ground into both (0369)
Lower Diagonal and (0349) Rock Rail as shown in g. 23.1. Attach using 2 (S3) #8 x 2-1/2” Wood Screws per
ground stake. (g. 23.2)
Wood Parts
Hardware
Fig. 23.1
4 x #8 x 2-1/2” Wood Screw
2 x Ground Stake 1-1/4 x 1-1/2 x 14”
0318
S3
Step 23: Attach Ground Stakes
MOVE FORT TO FINAL LOCATION. FINAL LOCATION MUST BE LEVEL GROUND
WARNING: To prevent tipping and avoid potential injury, stakes must
be driven 10-1/2” into ground. Digging or driving stakes can be dangerous
if you do not check rst for underground wiring, cables or gas lines.
S3
2223
2223
S3
10-1/2” Into Ground
Fig. 23.2
0318
0318
0349
0369
