8-22 Specifications PAS SERIES
*1 The maximum preset voltage and maximum preset current are provided for establishing
a constant current operation when the operation point is at [rated output voltage and
rated output current]. It does not guarantee power supply to the load exceeding the rated
output current.
To establish a constant voltage operation at the operation point [rated output voltage and
rated output current], set the output current (I Set) so that rated output current < I Set ≤
maximum preset current.
Likewise, to establish constant current operation, set the output voltage (V Set) so that
rate output voltage < V Set ≤ maximum preset voltage.
*2 The difference between the actual output current and the preset value under constant cur-
rent operation.
*3 ** % of rating denotes ** % of the rated output current.
*4 Output current fluctuation with respect to ± 10 % fluctuation of the nominal input volt-
age (ex. 100 VAC) under constant current operation.
*5 Output current fluctuation when the output current is set to the rated output current and
the load is changed from rated load to no load under constant current operation.
1 000W Type
PA S
10-105
PA S
20-54
PA S
40-27
PA S
60-18
PA S
80-13.5
Output Specifications (cont.)
Current
Rated output current 105.0 A 54.00 A 27.00 A 18.00 A
13.50 A
Maximum preset current
(typ)
*1
105 % of rating
Accuracy of setting
*2
0.5 % of rating + 20 mA
*3
Source effect
*4
0.1 % of rating + 15 mA
*3
Load effect
*5
0.1 % of rating + 15 mA
*3
Ripple noise (RMS)
*6
277 mA 143 mA 71 mA 48 mA 36 mA
Temperature coefficient
(max)
*7
200 ppm/ °C (during analog remote control)
Series/Parallel operation
Master-slave parallel operation
*8
Up to 2 units including the master unit (same models only)
Master-slave series operation
*9
Up to 2 units including the master unit (same models only)
Input Specifications
Current (max)
*10
15.0 A (100 VAC)/ 7.5 A (200 VAC)
Inrush current (max)
*11
105 Apeak
Power (max)
*10
1 500 VA
Power factor (typ)
*12
0.980
Efficiency (min)
*13
70%
To Next Page
