PAS SERIES Specifications 8-23
*6 At a measurement frequency bandwidth of 5 Hz to 1 MHz.
*7 At an ambient temperature range of 0 °C to 50 °C.
*8 The difference in the output current between the master unit and the slave unit is within
approximately 3 % of the rating.
*9 The difference in the output voltage between the master unit and the slave unit is within
approximately 3 % of the rating.
*10 Under rated load.
*11 Excludes the charge current component that flows through the capacitor of the internal
EMC filter circuit immediately after the POWER switch is turned on (within approxi-
mately 1 ms).
*12 Standard value at an input voltage of 100 VAC under rated load.
*13 At an input voltage of 100 VAC under rated load.
1 000W Type (cont.)
PA S
160-6
PA S
320-3
PA S
500-1.8
— —
Output Specifications (cont.)
Current Rated output current 6.000 A 3.000 A
1 800.0 mA
— —
Maximum preset current
(typ)
*1
105 % of rating — —
Accuracy of setting
*2
0.5 % of rating + 5 mA
*3
— —
Source effect
*4
0.1 % of rating + 5 mA
*3
— —
Load effect
*5
0.1 % of rating + 5 mA
*3
— —
Ripple noise (RMS)
*6
15 mA 10 mA 5 mA — —
Temperature coefficient
(max)
*7
200 ppm/ °C
(during analog remote control)
—
—
Series/Parallel operation
Master-slave parallel operation
*8
Up to 2 units including the master
unit (same models only)
—
—
Master-slave series operation
*9
Up to 2
units
including
the master
unit
(same
models
only)
impossible —
—
Input Specifications
Current (max)
*10
15.0 A (100 VAC)/ 7.5 A (200 VAC)
Inrush current (max)
*11
105 Apeak
Power (max)
*10
1 500 VA
Power factor (typ)
*12
0.980
Efficiency (min)
*13
70%
To Next Page
