Kinco SV100 Series User Manual

107
bit2
1
PLC running
0
Non-PLC running
bit3
1
Multi-section frequency
operation
0
Non multi-section
frequency operation.
bit4
1
Common operation
0
Non-common operation
bit5
1
Swing frequency
0
Non-swing frequency
bit6
1
Under voltage
0
Normal voltage
bit7
Reserved
bit8
Servo operation
bit9
Customized operation
bit10
Synchronous speed
operation
Others
Reserved
The bit definitions of VFD operating status word 3 are shown as following table:
Bit
Value
Function
Note
bit0~bit1
Reserved
bit2
Zero speed operation
bit3
Accelerating
bit4
Decelerating
bit5
Constant speed running
bit6
Pre-excitation
bit7
Tuning
bit8
Over-current limiting
bit9
DC over-voltage
limiting
bit10
Torque limiting
bit11
Speed limiting
bit12
VFD failure
bit13
Speed control
bit14
Torque control
bit15
Position control
1. Some instructions
1．For function code 0x10 and 0x43,when rewrite multiple continous function codes,if any one of the function
codes is invalid for write operation,then it will return error information and all of the parameters can’t be
rewritten.When rewrite multiple continuous control parameters,if any one of the parameters is invalid for write
operation, then it will return error information and this parameter and others behind can’t be rewritten,but other
parameters before this parameter can be rewritten normally.
2．For some special function code,Using 0x06 and 0x41 or 0x10 and 0x43 are the same function,in write
operation,the parameters can be saved after power failure.
Function code
Description
