Kinco SV100 Series User Manual

106
Register address
Parameters name
Note
0x3319
AI1
0x331A
AI2
0x331B
Length setting
Not support
0x331C
Acceleration time 1 setting
0x331D
Deceleration time 1 setting
0x331E
Methods of inputting
operating commands
0：Panel control
1：Terminal control
2：Communication control
0x331F
VFD operating status word 2
0x3320
Main reference frequency selector
0:Digital setting 1(Keypad ∧∨ setting)
1:Digital setting 2(Terminal UP/DN setting)
2:Digital setting 3 (Serial port)
3:AI analog setting
4:DI pulse setting
5:Expansion card.
0x3321
Accumulated length
Not support
Note:
（1）Status parameters don’t support write operation.
（2）The encoding rules of slave model is as follows:the range of slave model is 0~999.
The bit definitions of VFD operating status word 1 are shown in following table:
Bit
Value
Function
Note
bit0
1
VFD running
0
VFD stop
bit1
1
VFD reverse rotation
0
VFD forward rotation
bit2
1
Reach main reference
0
Not reach main reference
bit3
1
Serial port control enable
0
Serial port control disable
bit4
1
Serial port setting enable
0
Serial port setting disable
bit5~bit6
Reserved
bit7
1
Alarm
When this bit is 0,the bit15~8 of control word
1show the status.If bit15~8 are 0,means
normal.If not,means failure.
0
Fault or normal
bit15~ bit8
0x00~0xFF
Fault/alarm code
0: normal.
Not 0: fault/alarm.
The bit definitions of VFD operating status word 2 are shown in following table:
Bit
Value
Function
Note
bit0
1
Jog running
0
Non-jog running
bit1
1
Close loop running
0
Non-close loop running
