Kinco SV100 Series User Manual

38
extensive. You can select functions of X1~X5 according
to your application by setting A6.00~FA.04. Refer to
Table 6-1.
Table 6-1 Multi-function selection
Setting
Function
Setting
Function
0
No function
1
Forward
2
Reverse
3
Forward jog
operation
4
Reverse jog
operation
5
3-wire operation
control
6
External RESET
signal input
7
External fault
signal input
8
External interrupt
signal input
9
Drive operation
prohibit
10
External stop
command
11
DC injection
braking
command
12
Coast to stop
13
Frequency ramp
up (UP)
14
Frequency ramp
down (DN)
15
Switch to panel
control
16
Switch to terminal
control
17
Reserved
18
Main reference
frequency via AI1
19
Main reference
frequency via
AI2
20
Reserved
21
Reserved
22
Auxiliary
reference
frequency invalid
23
Reserved
24
Reserved
25
Reserved
26
Reserved
27
Preset frequency
1
28
Preset frequency 2
29
Preset frequency
3
30
Preset frequency 4
31
Acc/Dec time 1
32
Acc/Dec time 2
33
Reserved
34
Reserved
35
Reserved
36
Reserved
37
Forward prohibit
Setting
Function
Setting
Function
38
Reverse prohibit
39
Acc/Dec
prohibit
40
Reserved
41
Reserved
Introductions to functions listed in Table 6-1:
1: Forward.
2: Reverse.
3~4: Forward/reverse jog operation.
They are used to jog control of terminal control mo
de.The jog operation frequency,jog interval and jog
Acc/Dec time are defined by A2.04~A2.05,A4.05~A
4.06.
6: External RESET signal input.
The drive can be reset via this terminal when the drive
has a fault. The function of this terminal is the same with
that of RST on the panel.
7: External fault signal input.
If the setting is 7, the fault signal of external equipment
can be input via the terminal, which is convenient for the
drive to monitor the external equipment. Once the drive
receives the fault signal, it will display ―E015‖.
8. External interrupt signal input
If the setting is 8, the terminal is used to cut off the
output and the drive operates at zero frequency when the
terminal is enabled. If the terminal is disabled, the drive
will start on automatically and continue the operation.
9: Drive operation prohibits.
If terminal is enabled, the drive that is operating will
coast to stop and is prohibited to restart. This function is
mainly used in application with requirements of safety
protection.
10: External stop command.
This stopping command is active in all control
modes.When terminal 35 is enabled; the drive will stop
in the mode defined in A1.05.
11: DC injection braking command.
If the setting is 11, the terminal can be used to perform
DC injection braking to the motor that is running so as to
realize the emergent stop and accurate location of the
