Kinco SV100 Series User Manual

79
Function
code
Name
Descriptions
Unit
Factory
setting
Modif.
Setting
range
3：3-wire operation mode 2
A6.10
Reserved
A6.11
Reserved
A6.12
Reserved
A6.13
Input terminal’s
positive and
negative logic
Binary setting
0：Positive logic: Terminal Xi is
enabled if it is connected to
corresponding common terminal,
and disabled if it is disconnected.
1：Negative logic: Terminal Xi is
disabled if it is connected to
corresponding common terminal,
and enabled is it is disconnected.
Unit’s place of LED:BIT0~BIT3：
X1~X4
Ten’s place of LED:BIT0~BIT2：
X5~X7
1
00
○
0~FFH
6.14
Bi-direction
pen-collector
output terminal Y1
0：Running signal(RUN)
1：frequency arriving signal(FAR)
2：frequency detection threshold
(FDT1)
3：frequency detection threshold
(FDT2)
4：overload signal(OL)
5：low voltage signal(LU)
6：external fault signal(EXT)
7：frequency high limit(FHL)
8：frequency low limit(FLL)
9：zero-speed running
10：Terminal X1(Reserved)
11：Terminal X2(Reserved)
12：Reserved
13：Reserved
14：Reserved
1
0
×
0~20
