Kinco SV100 Series User Manual

80
Function
code
Name
Descriptions
Unit
Factory
setting
Modif.
Setting
range
15：Drive ready (RDY)
16：Drive fault
17:Switching signal of host
18：Reserved
19：Torque limiting
20:Drive running forward/reverse
Others:Reserved
A6.15
Reserved
1
1
×
0~20
A6.16
Output functions
of relay R1
The same as A6.14
1
15
×
0~20
A6.17
Reserved
1
16
×
0~20
A6.18
Ouput terminal’s
positive and
negative logic
Binary setting:
0: Terminal is enabled if it is
connected to
corresponding common terminal,
and disabled if it is disconnected.
1: Terminal is disabled if it is
connected to
corresponding common terminal,
and
enabled is it is disconnected.
Unit’s place of LED：
BIT0~BIT3：Y1、R1
Ten’s place of LED：
BIT0：Y2
1
0
○
0~1FH
A6.19
Frequency arriving
signal (FAR)
0.00~300.00Hz
0.01Hz
2.50Hz
○
0~30000
A6.20
FDT1 level
0.00~300.00Hz
0.01Hz
50.00Hz
○
0~30000
A6.21
FDT1 lag
0.00~300.00Hz
0.01Hz
1.00Hz
○
0~30000
A6.22
FDT2 level
0.00~300.00Hz
0.01Hz
25.00Hz
○
0~30000
A6.23
FDT2 lag
0.00~300.00Hz
0.01Hz
1.00Hz
○
0~30000
A6.24
Virtual terminal
setting
Binary setting
0：Disable
1：Enable
Unit’s place of LED：
1
00
○
0~FFH
