Kinco SV100 Series User Manual

81
Function
code
Name
Descriptions
Unit
Factory
setting
Modif.
Setting
range
BIT0~BIT3：X1~X4
Ten’s place of LED：
BIT0~BIT2：X5~X7
A6.25
Y2 terminal output
0~50：Y2 is used as Y terminal
output.
51~88：Y2 function
0:Running signal(RUN)
1:frequency arriving signal(FAR)
2:frequency detection threshold
(FDT1)
1
0
○
0~88
A6.25
Y2 terminal output
3:frequency detection threshold
(FDT2)
4:overload signal(OL)
5:low voltage signal(LU)
6:external fault signal(EXT)
7:frequency high limit(FHL)
8:frequency low limit(FLL)
9:zero-speed running
10：Terminal X1(Reserved)
11：Terminal X2(Reserved)
12：Reserved
13：Reserved
14：Reserved
15：Drive ready (RDY)
16：Drive fault
17:Switching signal of host
18：Reserved
19：Torque limiting
20 ： Drive running
forward/reverse
21~50：Reserved
51：Output frequency（0~ Max.
output frequency）
52：Preset frequency（0~ Max.
output frequency）
1
0
○
0~88
