Kinco SV100 Series User Manual

92
Function
code
Name
Descriptions
Unit
Factory
setting
Modif.
Setting
range
13
C0.13
Preset frequency
14
Same as above
0.01Hz
50.00Hz
○
0~30000
C0.14
Preset frequency
15
Same as above
0.01Hz
50.00Hz
○
0~30000
Group C1:Process PID parameters
C1.00
Close-loop control
function
0：Disable
1：Enable
1
0
×
0~1
C1.01
Reference channel
selection
0：Digital input
1：AI1；
2：AI2；
3：Reserved；
1
1
○
0~3
C1.02
Feedback channel
selection
0：AI1；
1：AI2；
2：AI1+AI2；
3：AI1-AI2；
4：MIN（AI1，AI2）；
5：MAX（AI1，AI2）；
6： Reserved
1
1
○
0~6
C1.03
Digital setting of
reference
-10.00V~10.00V
0.01
0.00
○
0~2000
C1.04
Close-loop speed
reference
0~39000rpm
1rpm
0
○
0~39000
C1.05
Min reference
0.0%~(C1.07)
(Ratio of Min reference to base
value of 10V/20mA))
0.1%
0.0％
○
0~1000
C1.06
Feedback value
corresponding to
the Min reference
0.0~100.0%
(Ratio of Min reference to base
value of 10V/20mA)
0.1%
0.0%
○
0~1000
C1.07
Max reference
(C1.05)~100.0%
(Ratio of Max reference to base
value of 10V/20mA)
0.1%
100.0%
○
0~1000
C1.08
Feedback value
corresponding to
the Max reference
0.0~100%
(Ratio of Max reference to base
value of 10V/20mA)
0.1%
100.0%
○
0~1000
