Kinco SV100 Series User Manual

94
Function
code
Name
Descriptions
Unit
Factory
setting
Modif.
Setting
range
reference 6
C1.25
Preset close-loop
reference 7
-10.00V ~10.00V
0.01V
0.00V
○
0~2000
C1.26
Preset close-loop
reference 8
-10.00V ~10.00V
0.01V
0.00V
○
0~2000
C1.27
Preset close-loop
reference 9
-10.00V ~10.00V
0.01V
0.00V
○
0~2000
C1.28
Preset close-loop
reference 10
-10.00V ~10.00V
0.01V
0.00V
○
0~2000
C1.29
Preset close-loop
reference 11
-10.00V ~10.00V
0.01V
0.00V
○
0~2000
C1.30
Preset close-loop
reference 12
-10.00V ~10.00V
0.01V
0.00V
○
0~2000
C1.31
Preset close-loop
reference 13
-10.00V ~10.00V
0.01V
0.00V
○
0~2000
C1.32
Preset close-loop
reference 14
-10.00V ~10.00V
0.01V
0.00V
○
0~2000
C1.33
Preset close-loop
reference 15
-10.00V ~10.00V
0.01V
0.00V
○
0~2000
C1.34
Close-loop output
reversal selection
0 ： The close-loop output is
negative,
the drive will operate at zero
frequency.
1 ： The close-loop output is
negative,
and the drive operate reverse.
1
0
○
0~1
Group d0:Status display
d0.00
Main reference
frequency
-300.00~300.00Hz
0.01Hz
0.00
*
0~60000
d0.01
Auxiliary
reference
frequency
-300.00~300.00Hz
0.01Hz
0.00
*
0~60000
d0.02
Preset frequency
-300.00~300.00Hz
0.01Hz
0.00
*
0~60000
d0.03
Frequency after
Acc/Dec
-300.00~300.00Hz
0.01Hz
0.00
*
0~60000
