SETTING UP YOUR FOOD PROCESSOR
Installing the adjustable slicing disc
1
Withtheworkbowlinstalled,place
the drive adapter on the power shaft
of the base.
2
Holding the adjustable slicing disc by
the2ngergrips,alignthepinsonto
the adjustable slicing disc adapter into
theL-slotsonthedisc.Slidethedisc
down onto the adapter and turn to
engage the pins in the L-slot.
3
Lower the slicing blade and slicing
adapter onto the drive adapter.
4
Installtheworkbowlcover,beingsure
it locks into place.
SETTING UP YOUR FOOD PROCESSOR
IMPORTANT: The adjustable slicing disc can only be installed in one direction.
TIP: You may need to turn the disc/drive adapter until it drops down into place.
