COMPACT AHU WITH HEAT RECOVERY EVO-T +
OPERATION AND MAINTENANCE MANUAL
106
Tabela Nr 23 Lista zmiennych:
DEC Address
Variable name Description States
Type Read [R]
/Write
[W]
BacNet Modbus BacNet Modbus
Menu główne
0 0 LanguageAct Currently selected menu language of the controller 1 – PL, 2 – EN, 16 – DE MSV Register R
1 2 ModeOnOTP Set operating mode – touch panel 0 – stop, 1 – start MSV Register R/W
2 4
ModeStdCal-
GearTP
Set operating mode – touch panel 1 – manual, 2 – calendar MSV Register R/W
3 6 SetGearTP Setting the manual mode – touch panel 1 = 1 IV Register R/W
4 8 StartSKhmi Sauna/replace function 0: Inactive, 1: Sauna, 2: Fireplace MSV Register R/W
5 10 Date Reading the current date in the controller Format date DV Register R
6 12 Time Reading the current time in the controller Format time TV Register R
7 14 UnitState System status (current)
0 – stop, 1 – operation 1 speed, 2 -Operation
2 speed, 4- operation 3 speed, 16 – cooling,
32 – heating, 64 – blocking alarm
MSV Register R
8 16 Mode Select the mode of operation
0: Stop, 1: Eco, 2: Comfort 4: Maximum, 8:
Calendar
MSV Register R/W
9 18 TsetCor Correction of temperature (±3°C) 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
10 20 SupEco Supply fan temperature setting in ECO mode 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
11 22 ExhEco Exhaust fan temperature setting in ECO mode 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
12 24 PaEco Pressure/output setting in ECO mode 1pa = 256 (22 pa = 22*256 = 5632 = 0x1600) AV Register R/W
13 26 TsetEco Temperature setting in ECO mode 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
14 28 SupComf Supply fan temperature setting in COMFORT mode 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
15 30 ExhComf Exhaust fan temperature setting in COMFORT mode 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
16 32 PaComf Pressure/output setting in COMFORT mode 1pa = 256 (22 pa = 22*256 = 5632 = 0x1600) AV Register R/W
17 34 TsetComf Temperature setting in COMFORT mode 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
18 36 SupMax Supply fan temperature setting in MAX mode 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
19 38 ExhMax Exhaust fan temperature setting in MAX mode 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
20 40 PaMax Pressure/output setting in MAX mode 1pa = 256 (22 pa = 22*256 = 5632 = 0x1600) AV Register R/W
21 42 TsetMax Temperature setting in MAX mode 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
