COMPACT AHU WITH HEAT RECOVERY EVO-T +
OPERATION AND MAINTENANCE MANUAL
112
DEC Address
Variable name Description States
Type Read [R]
/Write
[W]
BacNet Modbus BacNet Modbus
171 342 Kp_blow
Minimum and maximum intake temperature controller
amplication
1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
172 344 Ti_Blow
Integration constant of minimum and maximum intake
temperature controller
1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
173 346 KpFrost Amplication of the anti-frost cross recovery controller 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
174 348 TiFrost
Integration constant for the anti-frost cross recovery
controller
1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
175 350 Kp_CP Pressure controller amplication 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
176 352 Ti_CP Integration constant of the pressure regulator 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
177 354 KpCO2 CO2 limit controller amplication 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
178 356 TiCO2 Integration constant of the CO2 limit controller 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
179 358 KpH Humidity limit controller amplication 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
180 360 TiH Integration constant of the humidity limit controller 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
181 362 PumpTzON Pump switching function rel. 0 – nieaktywne, 1 – aktywne MSV 5792 R/W
182 364 TzON Tzew 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
183 366 MinValve
Limit of external temperature below which the circula-
tion pump continues to run
1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
184 368 ElOn Minimum heater valve opening 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
185 370 CoolHE Electric heater start-up delay in relation to fan start-up 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
186 372 FrostStop
Cooling down time of the electric heater when the
system is stopped
1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
187 374 FrostDeact
Supply air supply fan switch-o delay in the anti-frost
cross recovery mode
1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
188 376 FrostCycle
Anti-frost function deactivation period after completion
of an anti-frost cycle
1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
189 378 BypOpen
Defrost mode actuator cycles (1 – thermal, 2,3,4,5
actuator 3 pkt))
1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
190 380 BypBreak Bypass opening/closing contact switching time 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
191 382 ChRemStart Cooling down time of the thermal bypass actuator
0 – inactive, 1 – input D1, 2 – input D2, 3 –
input D3, 4 – input D4, 5 – input D5, 5 – input
D6
MSV Register R/W
192 384 ChA_AF Fire input function
0 – inactive, 1 – input D1, 2 – input D2, 3 –
input D3, 4 – input D4, 5 – input D5, 5 – input
D6
MSV Register R/W
193 386 ChWorkOut Operation conrmation output function
0 – inactive, 1 – PK1 output, 2 – PK2 output, 3
– PK3 output, 4 – PK4 output, 5 – PK5 output,
6 – PWM1 24VDC output, 7
- PWM2 24VDC output
MSV Register R/W
194 388 ChAlarmOut Collective alarm output function
0 – inactive, 1 – PK1 output, 2 – PK2 output, 3
– PK3 output, 4 – PK4 output, 5 – PK5 output,
6 – PWM1 24VDC output, 7
- PWM2 24VDC output
MSV Register R/W
195 390
ChLampU-
Vout
UV lamp power control output function
0 – inactive, 1 – PK1 output, 2 – PK2 output, 3
– PK3 output, 4 – PK4 output, 5 – PK5 output,
6 – PWM1 24VDC output, 7
- PWM2 24VDC output
MSV Register R/W
