111
DEC Address
Variable name Description States
Type Read [R]
/Write
[W]
BacNet Modbus BacNet Modbus
143 286 PM2_5max PM2.5 value setting for 10V signal
1µg/m3 = 256 (22µg/m3 = 22*256 = 5632
= 0x1600)
MSV Register R/W
144 288 PM10min PM10 value setting for 0V signal
1µg/m3 = 256 (22µg/m3 = 22*256 = 5632
= 0x1600)
MSV Register R/W
145 290 PM10max PM10 value setting for 10V signal
1µg/m3 = 256 (22µg/m3 = 22*256 = 5632
= 0x1600)
MSV Register R/W
146 292 LimH1
The humidity limit above which the system operates
with max output in order to decrease the humidity
1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
147 294 H10 Scaling the humidity sensor for 0VDC 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
148 296 H110 Scaling the humidity sensor for 10VDC 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
149 298 H1 Air supply humidity measurement 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R
150 300 LimCO2
The CO2 limit above which the system operates with max
output in order to decrease the CO2 concentration
1ppm = 256 (22ppm = 22*256 = 5632 =
0x1600)
AV Register R/W
151 302 CO20 Scaling the CO2 sensor for 0VDC voltage
1ppm = 256 (22ppm = 22*256 = 5632 =
0x1600)
AV Register R/W
152 304 CO210 Scaling the CO2 sensor for 10VDC voltage
1ppm = 256 (22ppm = 22*256 = 5632 =
0x1600)
AV Register R/W
153 306 CO2 CO2 measurement at air exhaust
1ppm = 256 (22ppm = 22*256 = 5632 =
0x1600)
AV Register R
154 308 Pa Pressure measurement 1Pa = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R
155 310 DPTrange Pressure sensor range 1Pa = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
Advanced Settings menu
156 312 SupVmin Minimum capacity of the supply air fan 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
157 314 ExhVmin Minimum capacity of the exhaust air fan 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
158 316 SupVMax Maximum intake fan airow rate 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
159 318 ExhVMax Maximum intake fan airow rate 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
160 320 OfsPT1
Correction of the measurement point of the temperature
sensorconnected to input PT1
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
161 322 OfsPT2
Correction of the measurement point of the temperature
sensorconnected to input PT2
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
162 324 OfsPT3
Correction of the measurement point of the temperature
sensorconnected to input PT3
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
163 326 OfsPT4
Correction of the measurement point of the temperature
sensorconnected to input PT4
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
164 328 OfsPT5
Correction of the measurement point of the temperature
sensorconnected to input PT5
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
165 330 OfsHMICon
Correction of the measurement point of the temperature
sensor connected to the HMI CON connector
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
166 332 RegType Choice of controller type (recommended type 2) 0: „1”, 1: „2” AV Register R/W
167 334 Kp_Heat Temperature controller amplication – heating 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
168 336 Ti_Heat Integration constant of temperature controller – heating 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
169 338 Kp_Cool Temperature controller amplication – Cooling 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
170 340 Ti_Cool Integration constant of temperature controller – Cooling 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
