COMPACT AHU WITH HEAT RECOVERY EVO-T +
OPERATION AND MAINTENANCE MANUAL
110
DEC Address
Variable name Description States
Type Read [R]
/Write
[W]
BacNet Modbus BacNet Modbus
113 226 SecHeat Heater 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R
114 228 RunC Cooler 0 – inactive, 1 – active MSV 3648 R/W
115 230 Y2 Cooler control level 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R
116 232 RunSK Activation of sauna/replace function 0 – inactive, 1 – active MSV 3712 R/W
117 234 Tsauna Cycle duration of system operation in the Sauna mode
1min = 256 (22min = 22*256 = 5632 =
0x1600)
AV Register R/W
118 236 Treplace Cycle duration of system operation in the replace mode
1min = 256 (22min = 22*256 = 5632 =
0x1600)
AV Register R/W
119 238 SupFire Air supply fan output setting in FIREPLACE mode 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
120 240 ExhFire Air exhaust fan output setting in FIREPLACE mode 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
121 242 Filter Counting lter operation time function 0 – inactive, 1 – active MSV 3872 R/W
122 244 Month Number of months of allowable lter operating time 1...6 IV Register R/W
123 246 LeftDays “Filter replacement in 1 = 1 (22 = 22) IV Register R
124 248 WorkTime Current working time 1h = 256 (22h = 22*256 = 5632 = 0x1600) AV Register R
125 250 SetTime Enter working time 1h = 256 (22h = 22*256 = 5632 = 0x1600) AV Register R/W
126 252 SetTimeRun Set running time counter 0 – No, 1 – Yes MSV Coil 4032 R/W
127 254
A_UVlampTi-
meAct
Activation of the A_UV_LampTime alarm UV lamp
(operating time overrun alarm)
0 – inactive, 1 – active MSV Coil 4064 R/W
128 256 UVmaxTime
Working time limit above which the UV lamps overrun
alarm is displayed
1h = 256 (22h = 22*256 = 5632 = 0x1600) AV Register R/W
129 258 PowESlter Power supply of electrostatic lter 0 – OFF, 1 -- ON MSV Register R
130 260 PM2_5 PM2.5 concentration measurement
1µg/m3 = 256 (22µg/m3 = 22*256 = 5632
= 0x1600)
AV Register R
131 262 PM10 PM10 concentration measurement
1µg/m3 = 256 (22µg/m3 = 22*256 = 5632
= 0x1600)
AV Register R
132 264 AirRegSensor Air quality sensor 1 – PM2.5, 2 – PM10 MSV Coil 4224 R/W
133 266 AirRegVent Activation of the air quality control function with air fans 0 – inactive, 1 – active MSV Coil 4256 R/W
134 268 Kp_Air Increase of the air quality control system 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
135 270 Ti_Air Integration constant of the air quality control system 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
136 272 SetPM2_5 PM2.5 concentration setting
1µg/m3 = 256 (22µg/m3 = 22*256 = 5632
= 0x1600)
AV Register R/W
137 274 SetPM10 PM10 concentration setting
1µg/m3 = 256 (22µg/m3 = 22*256 = 5632
= 0x1600)
AV Register R/W
138 276 SupPMlim
Minimum capacity of the supply air fan (for PM
controller)
1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
139 278 ExhPMlim
Minimum capacity of the exhaust air fan (for – PM
controller)
1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
140 280 UminAirReg Lower voltage threshold of the air quality sensor 1V = 256 (22 = 22*256 = 5632 = 0x1600) MSV Register R/W
141 282 UmaxAirReg Upper voltage threshold of the air quality sensor 1V = 256 (22 = 22*256 = 5632 = 0x1600) MSV Register R/W
142 284 PM2_5min PM2.5 value setting for 0V signal
1µg/m3 = 256 (22µg/m3 = 22*256 = 5632
= 0x1600)
MSV Register R/W
