Klimor EVO-T Plus - Page 111

109
DEC Address
Variable name Description States
Type Read [R]
/Write
[W]
BacNet Modbus BacNet Modbus
84 168 T6 Leading temperature history – reading 6 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
85 170 T7 Leading temperature history – reading 7 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
86 172 T8 Leading temperature history – reading 8 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
87 174 T9 Leading temperature history – reading 9 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
88 176 T10 Leading temperature history – reading 10 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
89 178 T11 Leading temperature history – reading 11 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
90 180 T12 Leading temperature history – reading 12 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
91 182 T13 Leading temperature history – reading 13 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
92 184 T14 Leading temperature history – reading 14 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
93 186 T15 Leading temperature history – reading 15 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
94 188 HistPeriod Temperature measurement period 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
95 190 Reset
Reset of measurements from the leading temperature
history
0 – o 1 – on MSV 3040 R/W
96 192 LowTempAct Low intake temperature alarm A_LowTemp 0 – inactive, 1 – active MSV 3072 R/W
97 194 TminSup Minimum permitted intake temperature 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
98 196 DelTemp Alarm delay for low intake temperature A_LowTemp 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
99 198 RunHeatPrim Activation of preliminary heating function
0 – inactive, 1 -- preliminary electric heater,
2 – GHEX
MSV Register R/W
100 200 ToHE1
Limit of external temperature below which the system
activates the anti-freeze protection function of the cross-
-ow recovery function as operation of the preliminary
electric heater
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
101 202 TsetRec
Setting of the requested air exhaust temperature
downstream heat recovery (preliminary electric heater
operates in function of this temperature)
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
102 204 YHE1 Control level of preliminary electric heater 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
103 206 ToGWCh
External temperature limit below which the system
initiates operation with the heat recovery using the GHEX
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
104 208 ToGWCc
External temperature limit above which the system
initiates the cool recovery using the GHEX
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
105 210 TimeO Time of turining ON the GHEX recovery Time (hh-m-sec) TV Register R/W
106 212 TimeOn
Time of turning OFF the GHEX (in order to enable the
bed regeneration)
Time (hh-m-sec) TV Register R/W
107 214 GWC Ground heat recovery 0 – stop, 1 – start MSV 3424 R
108 216 ToRECh
External temperature limit below which the system
initiates operation with the heat recovery using the
cross-ow recovery
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
109 218 ToRECc
External temperature limit above which the system
initiates the cool recovery using the cross-ow recovery
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
110 220 RecMode Manual and automatic heat recovery operation mode 0 – OFF, 1 – ON, 2 – Auto MSV Register R/W
111 222 recON Heat recovery status 0 – OFF, 1 -- ON, 2 – Anti-freeze MSV Register R
112 224 RunHeatSec Grzanie wtórne
0 – inactive, 1 -- electric heater, 2 – water
heater
MSV Register R/W
