COMPACT AHU WITH HEAT RECOVERY EVO-T +
OPERATION AND MAINTENANCE MANUAL
108
DEC Address
Variable name Description States
Type Read [R]
/Write
[W]
BacNet Modbus BacNet Modbus
54 108 PT_3 PT1000 Sensor input reading 3 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
55 110 PT_4 PT1000 Sensor input reading 4 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
56 112 PT_5 PT1000 Sensor input reading 5 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
57 114 HMI_Con
Sensor reading in the HMI controller connected via
HMI CON
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
58 116 Re1 Readout of condition of the relay output 1 0 – o, 1 – on MSV 1856 R
59 118 Re2 Readout of condition of the relay output 2 0 – o, 1 – on MSV 1888 R
60 120 Re3 Readout of condition of the relay output 3 0 – o, 1 – on MSV 1920 R
61 122 Re4 Readout of condition of the relay output 4 0 – o, 1 – on MSV 1952 R
62 124 Re5 Readout of condition of the relay output 5 0 – o, 1 – on MSV 1984 R
63 126 Do1proc Reading of control level of digital output PWM Do1 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R
64 128 Do1 Readout of condition of the digital output 24VDC Do1 0 – o, 1 – on MSV 2048 R
65 130 Do2proc Reading of control level of digital output PWM Do2 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R
66 132 Do2 Readout of condition of the digital output 24VDC Do2 0 – o, 1 – on MSV 2112 R
67 134 Aout1 Analogue output status reading 1 1V = 256 (22V = 22*256 = 5632 = 0x1600) AV Register R
68 136 Aout2 Analogue output status reading 2 1V = 256 (22V = 22*256 = 5632 = 0x1600) AV Register R
69 138 Aout3 Analogue output status reading 3 1V = 256 (22V = 22*256 = 5632 = 0x1600) AV Register R
70 140 Aout4 Analogue output status reading 4 1V = 256 (22V = 22*256 = 5632 = 0x1600) AV Register R
71 142 EntPas
Menu “Enter password” -– activation of user and
advanced settings
1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
User Settings menu
72 144 CalType Calendar type 1: K1, 2: K5+2, 4: K7 MSV Register R/W
73 146 ChTmain Selection of the lead sensor
1 – sensor in HMI programming device, 2 – air
supply, 3 – air exhaust, 4 – PT5 input
MSV Register R/W
74 148 TmaxBlow Maximum intake temperature 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
75 150 TminBlow Minimal supply temperature 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
76 152 TlimH
Limit of ambient temperature above which the system
locks the heating function
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
77 154 TlimC
Limit of external temperature below which the system
locks the cooling function
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
78 156 MaxDi
Maximum value of the setpoint temperature deviation and
the temperature from the leading temperature history
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
79 158 T1 Leading temperature history – reading 1 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
80 160 T2 Leading temperature history – reading 2 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
81 162 T3 Leading temperature history – reading 3 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
82 164 T4 Leading temperature history – reading 4 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
83 166 T5 Leading temperature history – reading 5 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
