COMPACT AHU WITH HEAT RECOVERY EVO-T +
OPERATION AND MAINTENANCE MANUAL
74
Table 2 Technical parameters EVO-T+5000
PARAMETERS EVO-T + 5000 CPR EVO-T + 5000 RR
Nominal air ow rate [m
3
/h] at External static pressure 500/150 Pa 500/70 Pa
Unit dimensions
L
[mm]
1400 1300
L1 689 639
B 712
B1 748
H 355
H1 395
Net weight [kg] / Gross weight with pallet 105 / 135 85/120
Flexible duct connections [mm] 315 x 290
Power supply voltage: 230 V; 50 Hz
Heat exchanger counterow rotary
Heat exchanger eciency* do 91% do 80%
Exchanger motor
Power
N/A
25 W
Voltage 230 V; 50 Hz
Absorbed current 0,23 A
Air temperature -25 do 50°C
Fans
Power 2×170 W
Voltage 230 V; 50 Hz
Absorbed current 2×1,4 A
Air temperature -25 do 50°C
Sound power level
To room at capacity
30% 35 dB(A) 35 dB(A)
100% 50 dB(A) 50 dB(A)
Into duct at air ow
30% 57dB / 50dB(A) 57dB / 50dB(A)
100% 66dB / 60dB(A) 66dB / 60dB(A)
Control system Digital controller
Exhaust and outlet air lter according to EN 779 / according to EN ISO 16890
G4/Coarse 80% – standard
M5 / ePM
10
50% – option
F7 / ePM
1
60% – option for air supply
EH heater on supply air inlet after heat recovery exchanger (option WH/EH) 2400W
*Note: Data provided by manufacturers of counterow plate heat exchangers, according to the EN 308 and EUROVENT
