Table 2 Settings list
CODE DESCRIPTION
Minimal brightness
(min brightness)
Brightness level when the HMI goes into operation mode
Maximal brightness
(max brightness)
Brightness level when the HMI goes into active mode
Active time (activity time) Time after which the HMI goes into standby mode when no key has been pressed
After activ.time (after activity time)
HMI activity when going into standby mode:
Nothing – no reaction (the LCD is dimmed only)
Alarms menu – when an HMI alarm occurs, it automatically goes to the alarm menu
Alarms/1st page –when there is an HMI alarm it automatically goes to the alarm menu, when there is no HMI
alarm it goes to the rst page (main page or rst page of the main menu)
T sensor oset (temperature sensor oset) Shifting the temperature measurement made by the built-in sensor.
Menu skin (menu skin) Possibility to select one of several menu designs
COMMUNICATION SETTINGS Communication settings
HMI COM SETTINGS(HMI
referencing-unit settings)
MAC address HMI address
Instance Unique device number in the network.
Bus mode (Bus operation mode) Way of communicating with the PLC controller
Com speed (HMI transmission speed) Serial transmission speed setting for HMI.
Com.parity Parity setting for communication with the PLC controller.
Com.stop bits Stop bits setting for communication with the PLC.
RS485 MA- STER COM.
SETTINGS (communication
settings via RS-485
MASTER)
MAC address PLC controller address
Instance Unique device number in the network.
Bus mode (bus operation mode) Possibility to choose the way of communication.
Com speed (HMI transmission speed) Serial transmission speed setting.
Com.parity Communication parity setting.
Com.stop bits Communication stop bits setting.
MULTI- DEVICE SETTINGS
(communication settings
for HMI working in MULTI
mode)
Multi-device display Choice of format for displaying controller description
Find device Sets the address area to search the network. Network search to nd devices.
