KLS Martin marLED E9 - Page 105

104 104 V. V. 1.01.0


Service ManualService Manual
Operating Lights marLEDOperating Lights marLED
®®
E9 / E9i / E15E9 / E9i / E15
Item
Item no. no. Name Name IllustrationIllustration
08-661-45-0408-661-45-04
Spring armSpring arm
marLEDmarLED
®®
E9 / E9iE9 / E9i
SD / HD 9-pin LCSD / HD 9-pin LC
08-661-53-0408-661-53-04
Spring arm marLEDSpring arm marLED
®®
E15 3-E15 3-
pin LCpin LC
08-661-52-0408-661-52-04
Spring arm marLEDSpring arm marLED
®®
E15 5-E15 5-
pin LCpin LC
08-661-51-0408-661-51-04
Spring arm marLEDSpring arm marLED
®®
E15E15
SD / HD 9-pin LCSD / HD 9-pin LC
08-674-05-0408-674-05-04
Securing segment / brakeSecuring segment / brake
screw AC2000screw AC2000
08-674-04-008-674-04-04 4 Securing Securing sleevesleeve
08-674-03-008-674-03-04 4 AC2000 AC2000 cover cover left left rightright
08-674-02-0408-674-02-04
Joint cover frontJoint cover front

to lamp bodyto lamp body
08-674-01-0408-674-01-04
Joint cover rearJoint cover rear

to support armto support arm
08-674-06-0408-674-06-04
Joint cover rearJoint cover rear

to support arm LCto support arm LC
