Service ManualService Manual
Operating Lights marLEDOperating Lights marLED
®®
E9 / E9i / E9 / E9i / E15E15
64 64 V V 1.01.0
••
Screw in center screws (2).Screw in center screws (2).
•• Turn the flaps in a way that the screws canTurn the flaps in a way that the screws can
be easily accessed with the screwdriver.be easily accessed with the screwdriver.
•• Screw in screws on the lamp casing (1).Screw in screws on the lamp casing (1).
••
Attach all Light Engines (see section 6.5 “”,Attach all Light Engines (see section 6.5 “”,
page 37).page 37).
